Roxar FD9 hard rock hydraulic drifter Features

Rotary percussive rock drill for holes up to 64mm

Shank Adapters: R38 / R32 (male/female) / R28 / H25 / H22

Percussion: High Energy per blow / Blow Frequency up to 70 Hz

Rotation: Max Torque 500 Nm / Max Speed 320 rpm

Weight: 60kg

Length: 675mm

Roxar FD9 hard rock hydraulic drifter
Main Applications

Face drilling

Anchoring,

Bolting,

Dimensional stones,

Light drilling attachment.

Roxar FD9 hard rock drifter Hydraulic Characteristics

Percussion flow rate: 30-70 l/min

Percussion pressure: auto-regulated

Rotation flow rate: 15-40l

Flushing: Air or Water

Reverse percussion

Roxar hard rock hydraulic drifter - FD9 rotary percussive drilling, High Performances 10kW Hydraulic Rock-drill

Roxar hard rock drifter - FD9 rotary percussive drilling, High Performances 10kW Hydraulic Rock-drill

Roxar hard rock hydraulic drifter FD9 – Efficient & Reliable hydraulic striking system – Compact dimensions & self-regulation of pressure for easy fitting on any machine – Modular system for wide choice of rotation motors – Heavy duty front head – Modular rear end permits coupling on any side – – Reverse percussion as a standard

Roxar FD9 hard rock hydraulic drifter, High Performances 10kW Hydraulic Rock-drill

Roxar FD9 hard rock hydraulic drifter featuring unique hydraulic system

Roxar FD9 hard rock drifter senses rock hardness, recovers and dampens the rebound energy,
Controls piston alternative motion,
continuously adjusts the strike energy & frequency,
Keeps the drill string & bit in constant contact with the rock for maximum shock-wave transmission.
